Products are widely used in industrial control system, household appliances, office system, and consumer electronics.
Product Description
Application: Internal wring or external interconnection of electronic equipment.
Application standard: UL758&UL1581&CSA C22.2 No.210 Product character: Excellent insulation performance, stable chemical properties Pass UL VW-1 and CSA FT1 vertical flame test Heat resistance, anti-acid and environmental protection etc. Constructure: Tinned or bare copper, stranded or single conductor (no.:2-50conductors) 36-16AWG,different conductor size may be used in one cord PP insulation Max core wire size:20AWG ,Flat or round Tinned or bare copper wire, spiral or braid shield or Al-mylar wrapped shield PU jacket(Halogen free material available) cable is either straight or spiral Technical parameter: Rated temperature : 60ºC Rated Voltage: 300V | Product Number | Conductor | Insulation | Shield | Jacket | Max. Cond. Resistance (200C)
Ω/km |
| | core | Size AWG | NO./mm | Conductor
Dia .
mm | Nom. Thickness
mm | Nom. Dia.
mm | Tape thick.
mm | Dia. of braid strand
mm | Nom. Thick. mm | Nom. Dia.
mm | |
| HT21007**101 | 3C | 28 | 7/0.127 | 0.38 | 0.26 | 0.80 | 0.025 | 0.10 | 0.80 | 3.80 | 223 |
| HT21007**102 | 3C | 26 | 7/0.16 | 0.48 | 0.26 | 0.90 | 0.025 | 0.10 | 0.80 | 4.04 | 140 |
| HT21007**103 | 3C | 24 | 11/0.16 | 0.60 | 0.26 | 1.12 | 0.025 | 0.10 | 0.80 | 4.51 | 87.6 |
| HT21007**104 | 3C | 22 | 17/0.16 | 0.76 | 0.26 | 1.30 | 0.025 | 0.10 | 0.80 | 4.90 | 55.4 |
| HT21007**105 | 6C | 28 | 7/0.127 | 0.38 | 0.26 | 0.80 | 0.025 | 0.12 | 0.80 | 4.70 | 223 |
| HT21007**106 | 6C | 26 | 7/0.16 | 0.48 | 0.26 | 0.90 | 0.025 | 0.12 | 1.00 | 5.30 | 140 |
| HT21007**107 | 6C | 24 | 11/0.16 | 0.60 | 0.26 | 1.12 | 0.025 | 0.12 | 1.00 | 6.00 | 87.6 |
Remark:Optional core wire number 2C-50C, and shielding way Detailed Photos
Company Profile
Founded in 2004 with 9 million USD capital investment, our HQ factory in Kunshan covers 14980 square meters.In 2020 we established our Nantong facility with 100 million RMB capital investment which covers 34000 square meters.With ISO9001, ISO14001, IATF16949, ISO13485 system certificates, all of our products have passed CCC, UL, CUL, CE, CSA, ETL safety certificates. We are working with global customers in various fields through our well-established sales system based on the management principal HONESTY, INNOVATION and ENVIRONMENTAL PROTECTION.
Certifications
Production Progress
Shipping
FAQ 1.Q:What can you supply?
A: We do produce consumer electronics wires, hock up wires, industrial cables, robot cables, ev charging cables, new/green energy cables.
2.Q: What are the certificates do you get?
A: We have UL, CE, 3C, Dekra, CQC, TUV, Rohs, Reach, ETL certificates.
3.Q:Can we get samples before ordering?
A:Yes, we are willing to arrange samples for you.
4.Q: What's your lead time?
A: Normally we can finish you orders in 2-3 weeks, and 5-6 weeks in peak season.
5.Q. How can you guarantee the product quality?
A: Always a pre-production sample before mass production and final Inspection before shipment.
Major Customers
